DeepCool PF600 600W PSU, 120mm Silent Hydraulic Bearing Fan, 80 PLUS White, Non Modular, UK Plug, Flat Black Cables, Efficient & Affordable
| Wattage | 600W |
| Size/Version | ATX |
| Modular | No |
| SATA Connections | 6 |
| Certification | White |
| Colour | Black |
£ 26.66
Guaranteed Safe Checkout
PF600
80 PLUS Standard Power Supply
The DeepCool PF Series Power Supply Unit offers safe and stable power performance with reliable 80 PLUS Standard efficiency and affordable pricing.
TO HIGHER STANDARDS
Certified for 80 PLUS 230V EU Standard efficiency that ensures 85% efficiency under typical loading of 50%. Better efficiency translates into lower energy waste and lower temperatures for more cost savings.
SILENT HYDRAULIC BEARING FAN
Optimally balanced for low-noise performance, the 120mm fluid bearing fan improves overall life expectancy and reduces friction and vibration.
FLAT BLACK CABLES
Stealthy and flexible, the fixed flat black cables are easy to maneuver for cable management while also taking up less space in your system.
RELIABLE PROTECTION
Shield against potential risk and damage with overpower, over voltage, and short circuit power protection.
OPP – Over Power Protection
OVP – Over Voltage Protection
SCP – Short Circuit Protection
UVP – Under Voltage Protection
Type
ATX 12V V2.4
80 PLUS Certifications
WHITE
Fan Size
120mm
Fan Bearing
Hydro Bearing
Topology
Active PFC + Double tube forward
Capacitors
Taiwan bulk capacitor
Power Good Signal
100-500ms
Hold Up Time
=16ms (75% Load)
Efficiency
=85% Under Typical Load (50% Loading)
Protection
OPP/OVP/SCP/UVP
Operation Temperature
0-40°C
Regulatory
CB/CCC/CE/UKCA/EAC/RCM/BIS
Regulation
ErP(2010)
MTBF
100,000 Hours
Main Power Connector
1 x 24-Pin (20+4)
EPS 12V Connector
2 x 8-Pin (4+4)
PCIE Connector
4 x 6+2 Pin
SATA Connector
6 x SATA
4-Pin Peripheral Connector
2 x 4-Pin
Product Dimension ( W x L x H )
150 x 140 x 86mm
Master Carton Quantity
5
| Weight | 1.85 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Manufacturer’s Website:
uk.deepcool.com
Warranty:
5 Years Return To Base Warranty
DESIGN
| Product colour | Black |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Fan location | Top |
ENERGY MANAGEMENT
| Input current | 4.5 A |
| Efficiency | 85% |
| Hold time | 16 ms |
| Power protection features | Over power, Over voltage, Short circuit, Under voltage |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 576 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 15 A |
| Max output current (+12V) | 48 A |
| Max output current (+5V) | 15 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| AC input frequency | 50 Hz |
| AC input voltage | 200 - 240 V |
| Total power | 600 W |
LOGISTICS DATA
| Harmonized System (HS) code | 84733020 |
OPERATIONAL CONDITIONS
| Operating temperature (T-T) | 0 - 30 °C |
OTHER FEATURES
| Harmonized System (HS) code | 84733020 |
PACKAGING CONTENT
| Cables included | AC, CPU, PCIe, Peripheral (Molex), SATA |
| Cable tie(s) included | Yes |
PACKAGING DATA
| Cables included | AC, CPU, PCIe, Peripheral (Molex), SATA |
PERFORMANCE
| Mean time between failures (MTBF) | 100000 h |
| Purpose | PC |
| Bearing technology | HYB |
| Supported motherboard form factors | ATX |
| ATX version | 2.4 |
| 80 PLUS certification | 80 PLUS White |
| Power supply unit (PSU) form factor | ATX |
PORTS & INTERFACES
| PCI Express connector | Yes |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| ATX power connector (20+4 pin) | Yes |
| CPU power connector (4+4 pin) | Yes |
| PCI Express power connectors (6+2 pin) | 4 |
| Cabling type | Non-Modular |
| Motherboard power cable length | 55 cm |
| SATA power cable length | 450 mm |
| CPU power cable length | 61 cm |
| Peripheral (Molex) power cable length | 150 mm |
| PCI Express power cable length | 51 cm |
| EPS power connector (4+4 pin) | Yes |
TECHNICAL DETAILS
| Sustainability certificates | ErP |
WEIGHT & DIMENSIONS
| Height | 86 mm |
| Width | 150 mm |
| Depth | 140 mm |
