Antec 550W CSK550 Cuprum Strike PSU, 80+ Bronze, Fully Wired, Antec’s 3-year warranty
| Wattage | 550W |
| Size/Version | ATX |
| Modular | No |
| SATA Connections | 7 |
| Certification | Bronze |
| Colour | Black |
£ 36.04
Guaranteed Safe Checkout
Antec’s new generation Cuprum Strike Bronze power supply is crafted for quality, efficiency, and performance.
Featuring 80 PLUS BRONZE certification, a quiet 120mm fan, CSK Bronze includes Antec’s 3-year warranty. The CircuitShield suite of industrial-grade protections ensure that the power delivered to your system is safe and reliable in any environment.
3-Year Warranty
We stand by the quality and safety of the CSK Bronze Power Supplies, offering a 3-year parts and labour warranty and unlimited access to our incomparable technical support and customer service.
120 mm Silent Fan
The 120 mm silent fan is ideal for quite computing and is designed for longer lifetime, guaranteeing hours of operation.
Specifications
Form Factor
ATX
Series
Antec Cuprum Strike
Wattage
550 W
Modular
Fully Wired
Compatability
ATX 12V 2.31
Connectors
1 x MB 24(20+4) Pin
1 x 8(4+4) Pin EPS 12V
2 x 8(6+2) Pin PCI-E
7 x SATA
2 x Molex
1 x FDD
AC Input
100 ~ 240 VAC
PFC
Active PFC
Fan Type
120mm Silent Fan
80+ Certification
80+ Bronze
Efficiency
88% Typically
Protection
OCP / OVP / UVP / SCP / OPP / NLO / OTP
Weight/Dimensions
1.71 kg
140(L) x 150(W) x 86(H) mm
Package Weight
2.0000 kg
Warranty
3 Years
| Weight | 1.9 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Manufacturer’s Website:
www.antec.com
Warranty:
3 Year Return To Base Warranty
CERTIFICATES
| Certification | cTUVus, TUV, CB, RCM, CE, CCC, FCC |
DESIGN
| Product colour | Black |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Cooling type | Active |
| Fan diameter | 12 cm |
ENERGY MANAGEMENT
| Input current | 10 - 5 A |
| Efficiency | 88% |
| Hold time | 500 ms |
| Power protection features | Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 110 W |
| Combined power (+12V) | 504 W |
| Combined power (+5V) | 110 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 14 A |
| Max output current (+12V) | 42 A |
| Max output current (+5V) | 16 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Total power | 550 W |
LOGISTICS DATA
| Warranty period | 3 year(s) |
OPERATIONAL CONDITIONS
| Operating temperature (T-T) | 0 - 40 °C |
PACKAGING DATA
| Package weight | 1.71 kg |
PERFORMANCE
| Certification | cTUVus, TUV, CB, RCM, CE, CCC, FCC |
| Purpose | PC |
| ATX version | 2.31 |
| 80 PLUS certification | 80 PLUS Bronze |
| Power supply unit (PSU) form factor | ATX |
PORTS & INTERFACES
| Motherboard power connector | 20+4 pin ATX |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 7 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| PCI Express power connectors (6+2 pin) | 2 |
| Cabling type | Non-Modular |
| Motherboard power cable length | 55 cm |
| SATA power cable length | 500,650,800 mm |
| Peripheral (Molex) power cable length | 650,800 mm |
| PCI Express power cable length | 65 cm |
| Floppy disk drive cable length | 95 cm |
| EPS power connector (4+4 pin) | Yes |
TECHNICAL DETAILS
| Warranty period | 3 year(s) |
WEIGHT & DIMENSIONS
| Weight | 1.53 kg |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 140 mm |
