AMD Ryzen 5 7500X3DAM5 Desktop Processor 12Threads, 4GHz up to 4.5GHz Boost, 96MB Cache, 65W.
£ 195.59
Guaranteed Safe Checkout
AMD Ryzen 5 7500X3D Desktop Processor
General Specifications
Name
AMD Ryzen 5 7500X3D
Family
Ryzen
Series
Ryzen 7000 Series
Form Factor
Desktops, Boxed Processor
Market Segment
Enthusiast Desktop
AMD PRO Technologies
No
Regional Availability
NA , EMEA
Former Codename
Raphael AM5
Processor Architecture
Zen 4
# of CPU Cores
6
Multithreading (SMT)
Yes
# of Threads
12
Max. Boost Clock
Up to 4.5 GHz
4 GHz
L1 Cache
384 KB
L2 Cache
6 MB
3 Cache
96 MB
Default TDP
65W
Processor Technology for CPU Cores
TSMC 5nm FinFET
Processor Technology for I/O Die
TSMC 6nm FinFET
CPU Compute Die (CCD) Size
71mm²
I/O Die (IOD) Size
122mm²
Package Die Count
2
AMD EXPO Memory Overclocking Technology
Yes
Precision Boost Overdrive
Yes
Yes
Yes
CPU Socket
AM5
Supporting Chipsets
A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850
CPU Boost Technology
Precision Boost 2
Instruction Set
x86-64
Supported Extensions
AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
Thermal Solution (PIB)
Not Included
Recommended Cooler
Liquid cooler recommended for optimal performance
Max. Operating Temperature (Tjmax)
89C
*OS Support
Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Connectivity
Native USB 3.2 Gen 2 (10Gbps)
4
Native USB 3.2 Gen 1 (5Gbps)
0
Native USB 2.0 (480Mbps)
1
PCI Express Version
PCIe 5.0
Native PCIe Lanes (Total/Usable)
28 , 24
NVMe Support
Boot , RAID0 , RAID1 , RAID10
System Memory Type
DDR5
Memory Channels
2
Max. Memory
128 GB
System Memory Subtype
UDIMM
Max Memory Speed
2x1R DDR5-5200
2x2R DDR5-5200
4x1R DDR5-3600
4x2R DDR5-3600
ECC Support
Yes (Requires mobo support)
Graphics Capabilities
Graphics Model
AMD Radeon Graphics
Graphics Core Count
2
Graphics Frequency
2200 MHz
USB Type-C DisplayPort Alternate Mode
Yes
Key Features
Supported Technologies
AMD EXPO Technology , AMD Ryzen Technologies
| Weight | 0.0 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Manufacturer’s Website:
www.amd.co.uk
Warranty:
AMD Processors in a box (PIB): 3 Year Limited Manufacturer Warranty.
Coverage
Year 1: Return to Target or AMD for warranty service.
Years 2-3: Warranty service provided directly by AMD
AMD Warranty Support
AMD Warranty Portal: https://www.amd.com/en/registration/warranty-services-portal.html
Please Note: First-time users must create an AMD account to access warranty services.
AMD Help & Support: https://www.amd.com/en/support.html
Required Documentation for AMD Warranty Claims
1. Product details including serial number and model number.
2. Clear explanation of the problem you’re experiencing
3. Proof of purchase (receipt or invoice).
4. Photo of the CPU
FEATURES
| PCI Express slots version | 5.0 |
| Maximum number of PCI Express lanes | 28 |
| Market segment | Desktop |
GRAPHICS
| On-board graphics card model | AMD Radeon |
| Discrete graphics card model | Not available |
| On-board graphics card | Yes |
| Discrete graphics card | No |
MEMORY
| ECC | Yes |
| Non-ECC | Yes |
| Memory channels | Dual-channel |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory clock speeds supported by processor | 3600,5200 MHz |
OTHER FEATURES
| L1 cache | 0.384 MB |
| L2 cache | 6144 KB |
PACKAGING DATA
| Package type | Box |
PROCESSOR
| Processor model | 7500X3D |
| Processor manufacturer | AMD |
| Processor lithography | 5 nm |
| Processor family | AMD Ryzen™ 5 |
| Processor socket | Socket AM5 |
| Package type | Box |
| Processor cores | 6 |
| Processor threads | 12 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.5 GHz |
| Processor cache | 96 MB |
| Thermal Design Power (TDP) | 65 W |
| Processor codename | Raphael AM5 |
| Processor cache type | L3 |
| Cooler included | No |
| Generation | Zen 4 |
| Processor base frequency | 4 GHz |
| Processor generation | AMD Ryzen 7000 Series |
