Ubiquiti UISP Wave Access Point – Wave-AP

Ubiquiti UISP Wave Access Point – Wave-AP

The Ubiquiti Wave-AP 60 GHz PtMP access point, powered by Wave Technology, is a remarkable piece of networking hardware that can seamlessly connect up to 15 stations with high-speed internet. The Wave Access Point has a total throughput of up to 5.4 Gbps, which is twice the duplex throughput of 2.7 Gbps.

The Ubiquiti Wave-AP has a high-performance 5 GHz backup radio to ensure an uninterrupted connection, even during power outages. In addition, the device is equipped with a Bluetooth radio, which allows for easy setup through the UISP Mobile app.

One of the most impressive features of the Wave Access Point is its support for stations and distances. Wave Long-Range stations can be connected up to 8 km away, while Wave Nano stations can be connected up to 5 km away. This is particularly useful for rural areas where internet connectivity is scarce.

The UISP Wave-AP also comes with two WAN ports, including one 10G SFP+ port and one 2.5GbE port, which enable high-speed connectivity. The access point also has an integrated GPS antenna that helps with location tracking and provides accurate timestamps.

Link planning support is also available through the ISP Design Centre. This enables network engineers to design, plan and implement their networks with greater accuracy and reliability. With all these features and functionalities, the Ubiquiti Wave-AP 60 GHz PtMP access point is an excellent choice for high-speed internet connectivity.

Key Features
5 GHz backup radio
Supported stations and distances:
– Wave Long-Range: up to 8 km
– Wave Nano: up to 5 km
WAN Ports: (1) 10G SFP+, (1) 2.5GbE
Integrated GPS antenna
Link planning support via the ISP Design Centre

Specifications

Mechanical

Dimensions
212 x 205 x 187 mm (8.3 x 8.1 x 7.4″)
Weight 2.3 kg (5.07 lb)

Enclosure materials
Aluminum alloy, UV stabilized polycarbonate

Pole mount diameter
25 to 76 mm (1 to 3″) on pipe outer diameter

Wind loading
98 N at 200 km/h (22 lbf at 125 mph)

Weatherproofing
IPX6

Hardware

Processor
Quad ARM Cortex -A53 cores at 1.4 GHz

Memory
DDR3L
512 MB

Networking interface
1 x 2.5GbE RJ45 port (100/1000/2500)
1 x 10G SFP+ port (1/10)
Active only when SFP+ port is down

Max. power consumption
24W

Power method
48V DC passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) or 2-pairs (4, 5+; 7, 8-)
24V DC passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)

Power supply
48V DC, 0.65A 2.5GbE PoE adapter (included)

GPS
Yes

Button
Factory reset

LEDs
Power, Ethernet, GPS

Operating temperature
-40 to 60° C (-40 to 140° F)

Operating humidity
5 to 95% noncondensing

Certifications
FCC, IC, CE

Software

OS
airOS

Operating mode
PtMP access point

Ubiquiti specific features
Wave AI, discovery protocol

Services
UISP, ping watchdog, NTP client, SNMP

Tools
Antenna alignment, discovery utility, ping, trace route, speed test

Network
Bridge mode

Software management
Bluetooth management for easy setup over UISP Mobile app
WEB UI

Minimum software requirements
Any modern web browser/iOS or Android based smartphone

System

Total throughput
5.4 Gbps (2.7 Gbps duplex)

Supported clients count
15

Range
Connecting to a Wave Long-Range: up to 8 km
Connecting to a Wave Nano: up to 5 km

EncryptionWPA2-PSK (AES)

RF

Operating frequency
57 to 71 GHz
Depends on regulatory region.

Channel bandwidth
2160, 1080 MHz

Operating channels
58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz
Depends on regulatory region.

Modulation
16QAM, QPSK

Antenna gain
24 dBi

Polarization
Vertically linear

Beamwidth
Azimuth: 30°
Elevation: 3 dB 3°, 6 dB 4°

Electrical downtilt
0°

Back-Up RF

WiFi standard
802.11ax (WiFi 6)

Operating frequency US/CA
U-NII-1 5150 – 5250 MHz
U-NII-2A 5250 – 5350 MHz
U-NII-2C 5470 – 5725 MHz
U-NII-3 5725 – 5850 MHz

Worldwide
5150 – 5875 MHz
Depends on regulatory region.

Channel bandwidth
20, 40, 80 MHz

Modulation
BPSK (1/2), QPSK (1/2), QPSK (3/4), 16QAM (1/2), 16QAM (3/4), 64QAM (2/3), 64QAM (3/4), 64QAM (5/6), 256QAM (3/4), 256QAM (5/6), 1024QAM (3/4), 1024QAM (5/6)

Antenna gain
12 dBi

Cross-pol isolation
10 dB

Electric downtilt
0°

LEDs

Power
Flashing white: bootup in progress
White: not connected to UISP application
Blue: connected to UISP application
Flashing blue: locate in progress
Blue/white: firmware upgrade in progress

Ethernet
Flashing white: Ethernet traffic detected
Flashing blue: SFP+ traffic detected

GPS
Blue: receiving at least (4) GPS satellite signal

Box Contents
1x Wave AP
1x Pole Mount Kit (Screws Included)
1x Zip Tie
1x Gigabit PoE Adapter (48V, 0.65A)
