Ubiquiti UVC-G5-PTZ G5 Compact All-Weather Pan Tilt Zoom Camera – White
| Camera Resolution | 2688x1512 |
| Camera Type | PTZ |
| POE Capability | 48v |
| Pack Size | Single |
£ 198.52
Guaranteed Safe Checkout
Compact, all-weather camera with ultra-low latency pan-tilt-zoom control and versatile mounting options.
Specifications
Dimensions
Without mount: d90 x 152.5 mm
(d3.5 x 6″)
With mount: 90 x 94 x 179.5 mm
(3.5 x 3.7 x 7″)
IR Night Vision
20 m (65 ft)
Optical Zoom
2K
Smart Detections (People, Vehicles, Animals)
Yes
Resolution
2K
Field of View
Wide: H: 99.7d, V: 51.9d, D: 121d
Tele: H: 45.5d, V: 25.4d, D: 52.4d
Audio
Microphone
Weatherproofing
IP66
Tamper Resistance
IK04
Mounting
Wall mount, pole mount (Included)
Conduit adapter, surface, in-ceiling, pendant, corner mount (Optional)
UniFi Application Suite
Protect
Networking Interface
10/100 MbE RJ45 Port
Video
Max Frame Rate: 30 FPS
Resolution: 4MP 2688 x 1512 (16:9)
Optics
Sensor: 5MP 1/2.7″ CMOS
Lens: F 3.42–6.85 mm; ?/1.85–?/2.4
Night Mode: Built-in IR & white LED illumination with IR cut filter
Hardware
Max. Power Consumption
14W
Supported Voltage Range
37 – 57V DC
Power Method
PoE+
Pole Mount Diameter
1.5–2″ (38–50 mm)
Weight
Without mount: 580 g (1.3 lb)
With mount: 650 g (1.4 lb)
Enclosure Material
Aluminum alloy, polycarbonate
Mount Material
Wall mount: polycarbonate
Pole mount: aluminum alloy
Button
(1) Factory-reset
| Weight | 0.95 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.
AUDIO
| Built-in microphone | Yes |
CAMERA
| Lens viewing angle, horizontal | 99.7° |
| Lens viewing angle, vertical | 51.9° |
| Lens viewing angle, diagonal | 121° |
DESIGN
| Form factor | Dome |
| Product colour | White |
| Mounting type | Wall/Pole |
| International Protection (IP) code | IP66 |
| IK code | IK04 |
| Weatherproof | Yes |
ENERGY MANAGEMENT
| DC output voltage | 37, 57 |
| Power source type | DC, PoE |
IMAGE SENSOR
| Sensor type | CMOS |
| Optical sensor size | 50.8 / 7 mm (2 / 7") |
| Number of sensors | 1 |
LENS SYSTEM
| Focal length range | 3.42–6.85 |
| Minimum aperture number | 1.85 |
| Maximum aperture number | 2.4 |
NETWORKING
| Ethernet LAN | Yes |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet interface type | Fast Ethernet |
NIGHT VISION
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 20 m |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | -30 - 45 °C |
PACKAGING CONTENT
| Mounting kit | Yes |
| Number of cameras | 1 |
PERFORMANCE
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| PTZ control | Yes |
PORTS & INTERFACES
| Ethernet LAN (RJ-45) ports | 1 |
STORAGE
| Built-in HDD | No |
VIDEO
| Maximum resolution | 2688 x 1512 pixels |
| Total megapixels | 4 MP |
WEIGHT & DIMENSIONS
| Weight | 580 g |
| Height | 90 mm |
| Diameter | 15.2 cm |
