Ubiquiti (USW-Pro-XG-48) Professional-grade, 48-port Layer 3 Etherlighting switch with (32) 10 GbE, (16) 2.5 GbE, and (4) 25G SFP28 ports.

Speed	10G
Ports	52
POE Capability	No
Managed or Unmanaged	Unmanaged
Rack Mountable	Yes

£ 1,398.52

Add to wishlist

Guaranteed Safe Checkout

Ubiquiti Pro XG 48 Switich

Professional-grade, 48-port Layer 3 Etherlightin switch with (32) 10 GbE, (16) 2.5 GbE, and (4) 25G SFP28 ports.

Specifications

Overview

Dimensions
442 x 480 x 44 mm
(17.4 x 18.9 x 1.7″)

Port Layout
2.5 GbE RJ45 – 16 (2.5G/1G/100M/10M)
10 GbE RJ45 – 32 (10G/5G/2.5G/1G/100M/10M)
25G SFP28 – 4 (25G/10G/1G)

Redundancy
DC Power Backup

Layer 3
Yes

Form Factor
Rack mount (1U)

Etherlighting
Yes

Performance

Switching Capacity
920 Gbps

Total Non-Blocking Throughput
460 Gbps

Forwarding Rate
684 Mpps

Supported VLANs
1,000

MAC Address Table Size
128,000

L3 Table Size
ARP Entries -128,000
IPv4 Routes – 256,000

Packet Buffer Size
8 MB

Access Lists
IPv4
256
MAC
256

Layer 3 Features

DHCP Server (Local Networks) – Yes
DHCP Relay – Yes
Inter-VLAN Routing (Local Networks) – Yes
Static Routing (Local Networks) – Yes

Layer 2 Features
LACP Port Aggregation – Yes
STP & RSTP – Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port) – Yes
IGMP Snooping – Yes
802.1X Control – Yes
MAC-Based ACLs & Device Isolation – Yes
DHCP Snooping & Guarding – Yes
Egress Rate Limit – Yes
Flow Control – Yes
Storm Control – Yes
Multicast & Broadcast Rate Limiting – Yes
MAC Address Blocking – Yes
IP-Based ACLs & Network Isolation – Yes
MAC-Based Port Restriction – Yes
Port Isolation – Yes
Port Mirroring – Yes
Jumbo Frames – Yes
LLDP-MED – Yes
Voice VLAN – Yes
Loop Protection – Yes

Hardware

Max. Power Consumption
250W

Power Method
(1) Universal input, 100—240V AC, 50/60 Hz
(1) USP RPS DC input

Power Input Method
AC input

Power Supply
AC/DC, internal, 300W

Supported Voltage Range
100—240V AC

Management
Ethernet
AR

Weight
Without mounting brackets: 7.5 kg (16.5 lb)
With mounting brackets: 7.6 kg (16.8 lb)

Enclosure Material
SGCC steel

Mount Material
SGCC steel

Supported Rack Depth
482.6 mm (19″) four-post racks
Posts depths ranging from 600 to 1,066 mm (23.6-42?)

LCM Display
1.3″ touchscreen

ESD Protection
Air: ± 30kV, contact: ± 14kV

Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing

LEDs
RPS – Yes
NDAA Compliant – Yes

Certifications
CE, FCC, IC

Software

Application Requirements
UniFi Network
Version 9.0.114 and later

Weight	5.5 lbs
Manufacturer	UBIQUITI
EAN	810177160748
Manufacturer Code	USW-Pro-XG-48

Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.

CERTIFICATION

Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA)

DATA TRANSMISSION

MAC address table	128000 entries
Switching capacity	920 Gbit/s
Jumbo frames support	Yes
Forwarding rate	684 Mpps
Packet buffer memory	8 MB
Static route	Yes
Throughput	460 Gbit/s

DESIGN

Rack mounting	Yes
Form factor	1U
Backlight display	Yes
Product colour	Grey
Stackable	Yes
Reset button	Yes
Housing material	SGCC
Display type	LCM

ENERGY MANAGEMENT

Power source	AC/DC
Redundant power supply (RPS) support	Yes
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Power consumption (max)	250 W
Power supply included	Yes

MANAGEMENT FEATURES

Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Switch type	Managed

MULTICAST FEATURES

Multicast support	Yes

NETWORKING

Flow control support	Yes
Port mirroring	Yes
Broadcast storm control	Yes
Rate limiting	Yes
Number of VLANs	1000
VLAN support	Yes
10G support	Yes
Virtual LAN features	Interface-based VLAN, Voice VLAN
IPv4 routes	256000

OPERATIONAL CONDITIONS

Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-5 - 40 °C

PACKAGING CONTENT

Cables included	Power
Rack mount kit	Yes

PACKAGING DATA

Cables included	Power
Rack mount kit	Yes

PORTS & INTERFACES

Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	48
Power connector	AC/DC
SFP28 ports quantity	4
2.5G Ethernet (copper) ports quantity	16
10G Ethernet (copper) ports quantity	32

POWER OVER ETHERNET (POE)

Power over Ethernet (PoE)	No

SECURITY

IGMP snooping	Yes
Loop protection	Yes
Access Control List (ACL) IPv4 entries	256
DHCP features	DHCP guarding, DHCP relay, DHCP server, DHCPv6 snooping
