Ubiquiti USW-PRO-8-POE UniFi Switch Pro 8 Port Layer 3 POE++ Managed Switch
| Speed | Gigabit |
| Ports | 8 |
| POE Capability | 48v |
| Managed or Unmanaged | Managed |
| Rack Mountable | No |
£ 208.40
Guaranteed Safe Checkout
Ubiquiti UniFi USW-Pro-8-PoE Professional 8 Port PoE Switch
Key Features
An 8-port, Layer 3 switch
6 x GbE PoE+ ports
2 x GbE PoE++ ports
2 x 10G SFP+ ports
120W total PoE availability
The Ubiquiti UniFi USW-Pro-8-PoE is an advanced 8-port, Layer 3 switch that offers both PoE+ and PoE++ outputs. This switch is equipped with six Gigabit Ethernet (GbE) PoE+ ports and two GbE PoE++ ports, along with two 10G SFP+ ports, providing versatile connectivity options. It offers a total Power over Ethernet (PoE) availability of 120W.
The USW-Pro-8-PoE’s enclosure is made from a combination of plastic and metal, ensuring durability. The device features an Ethernet In-Band management interface and a 1.3″ touchscreen LCM display for easy control and monitoring. It supports a total non-blocking throughput of 28 Gbps and a switching capacity of 56 Gbps.
USW-Pro-8-PoE uses a universal input of 100–240V AC, with a maximum power consumption of 30W (excluding PoE output). The switch provides a maximum PoE wattage per port of 15W for PoE, 30W for PoE+, and 60W for PoE++.
The USW-Pro-8-PoE is certified by CE, FCC, and IC, and is managed with UniFi Network Application version 7.5.176 or later.
Specifications
Mechanical
Weight & Dimensions
200 x 248 x 44 mm
2.1 kg
Enclosure materials
Polycarbonate, metal
Mount material
Polycarbonate
Hardware
Management interface
Ethernet In-Band
Networking interface
(8) GbE RJ45 ports
(2) 10G SFP+ ports
PoE interface
(6) PoE/PoE+ (Pins 1, 2+; 3, 6-)
(2) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Total non-blocking throughput
28 Gbps
Switching capacity
56 Gbps
Power method
Universal input, 100—240V AC, 2A Max.
Power supply
AC/DC, internal
Supported voltage range
100—240V AC
Max. power consumption
30W (Excluding PoE output)
Total available PoE
120W
Max. PoE wattage per port by PSE
PoE: 15W
PoE+: 30W
PoE++: 60W
Voltage range PoE mode
PoE: 44—57V
PoE+: 50—57V
PoE++: 50—57V
LCM display
(1) 1.3″ touchscreen
LEDs
RJ45 ports: link/activity
Button
Factory reset
Operating temperature
-5 to 45° C (23 to 113° F)
Operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Application Requirements
UniFi Network
Version 7.5.176 and later
| Weight | 2.7 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.
CERTIFICATION
| Certification | CE, FCC, IC |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
DATA TRANSMISSION
| Switching capacity | 56 Gbit/s |
| Jumbo frames support | Yes |
| Static route | Yes |
| Throughput | 28 Gbit/s |
DESIGN
| Certification | CE, FCC, IC |
| Form factor | 1U |
| LED indicators | Activity, Link, PoE, Speed, System |
| Product colour | White |
| Housing material | Metal, Plastic |
ENERGY MANAGEMENT
| Number of power supply units | 1 |
| Power source | AC/DC |
| Input current | 2 A |
| AC input voltage | 100 - 240 V |
| Power supply included | Yes |
MANAGEMENT FEATURES
| Switch layer | L2/L3 |
| Switch type | Managed |
NETWORKING
| Full duplex | Yes |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Flow control support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Auto MDI/MDI-X | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| 10G support | Yes |
| Copper ethernet cabling technology | 10BASE-T, 10BASE-TX, 100BASE-FX, 100BASE-TX |
| Auto-sensing | Yes |
| Half duplex | Yes |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -5 - 45 °C |
PACKAGING CONTENT
| Manual | Yes |
PACKAGING DATA
| Manual | Yes |
PORTS & INTERFACES
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| SFP+ module slots quantity | 2 |
POWER OVER ETHERNET (POE)
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 6 |
| Total Power over Ethernet (PoE) budget | 120 W |
| Power over Ethernet (PoE) power per port | 60 W |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 2 |
SECURITY
| Authentication type | IEEE 802.1x, RADIUS |
| Authentication | Port-based authentication |
| DHCP features | DHCP server |
SUSTAINABILITY
| Sustainability compliance | Yes |
| Sustainability certificates | CE, Federal Communications Commission (FCC) |
TECHNICAL DETAILS
| Sustainability compliance | Yes |
| Sustainability certificates | CE, Federal Communications Commission (FCC) |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
WEIGHT & DIMENSIONS
| Weight | 2.1 kg |
| Height | 44 mm |
| Width | 200 mm |
| Depth | 248 mm |
