Ubiquiti USW-Aggregation UniFi 8 Port 10Gb SFP+ Layer 2 Aggregation Switch
| Speed | 10G |
| Ports | 8 |
| POE Capability | No |
| Managed or Unmanaged | Managed |
| Rack Mountable | Yes |
£ 180.53
Guaranteed Safe Checkout
Ubiquiti UniFi Switch Aggregation (USW-Aggregation)
Layer 2 switch with (8) 10G SFP+ ports
The Switch Aggregation is a fully managed, Layer 2 switch with (8) 10G SFP+ ports designed to enhance your network’s switching capacity and performance by creating high-bandwidth aggregation links. This rack-mountable switch also offers 160 Gbps switching capacity and features a 1.3″ LCM color touchscreen that concisely displays key system and connection insights. Additionally, with its 4.7″ depth, it’s easy to mount this compact, fanless switch in a SOHO rack cabinet. This switch can be monitored or configured from anywhere with the powerful, intuitive
Hardware
Total Non-Blocking Throughput
80 Gbps
Switching Capacity
160 Gbps
Forwarding Rate
119.04 Mpps
Max Power Consumption
30W
Power Method
Universal AC Input: 100-240VAC, 50/60 Hz
Power Supply
AC/DC, Internal, 36W
Management Interface
Ethernet In-Band
Modes
SMB Layer 2 Gigabit Ethernet Switch
Max. Number of Supported SFP+ Modules
UACC-OM-MM-10G – 8
UACC-OM-SM-10G – 8
UACC-CM-RJ45-10G – 4
ESD/EMP Protection
Air: ± 16kV, Contact: ± 12kV
Operating Temperature
-5 to 40° C (23 to 104° F)
Operating Humidity
10 to 90% Noncondensing
Certifications
CE, FCC, IC
LEDs
System
(1) Bootup Animation: Bootup in Progress
Firmware Upgrade Icon: Firmware Upgrading
Steady White: Factory Defaults, Awaiting Adoption
Steady Blue: Device is Adopted
SFP+
White: 1/10G
Packaging
Weight
Without Mount: 2.65 kg (5.84 lb)
With Mount: 2.74 kg (6.04 lb)
Dimensions
442.4 x 120 x 43.7 mm (17.42 x 4.72 x 1.72″)
Enclosure Material
SGCC Steel
Warranty
1 Year
| Weight | 4.25 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.
CERTIFICATION
| Certification | CE, FCC, IC |
DATA TRANSMISSION
| Switching capacity | 160 Gbit/s |
| Forwarding rate | 119.04 Mpps |
| Throughput | 80 Gbit/s |
DESIGN
| Certification | CE, FCC, IC |
| Rack mounting | Yes |
| Form factor | 1U |
| LED indicators | System |
| Product colour | Silver |
| Housing material | Galvanized steel |
ENERGY MANAGEMENT
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 30 W |
| Power supply included | Yes |
LOGISTICS DATA
| Harmonized System (HS) code | 85176990 |
MANAGEMENT FEATURES
| Switch layer | L2 |
| Switch type | Managed |
NETWORKING
| 10G support | Yes |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -5 - 40 °C |
PACKAGING CONTENT
| Cables included | AC |
| Rack mount kit | Yes |
PACKAGING DATA
| Cables included | AC |
| Rack mount kit | Yes |
PERFORMANCE
| Fanless | Yes |
| Harmonized System (HS) code | 85176990 |
PORTS & INTERFACES
| Basic switching RJ-45 Ethernet ports type | No |
| SFP+ module slots quantity | 8 |
POWER OVER ETHERNET (POE)
| Power over Ethernet (PoE) | No |
WEIGHT & DIMENSIONS
| Weight | 2.65 kg |
| Height | 43.7 mm |
| Width | 442.4 mm |
| Depth | 120 mm |
