Ubiquiti USW-24-POE UniFi Gen2 24 Port Gigabit Network Switch with 16 PoE+ Ports
| Speed | Gigabit |
| Ports | 24 |
| POE Capability | 48v |
| Managed or Unmanaged | Managed |
| Rack Mountable | Yes |
£ 261.52
Guaranteed Safe Checkout
Powerful Hardware and Software
UniFi Switches offer a variety of features, including 10G SFP+ ports, PoE+ or PoE++ support, and Layer 3 switching capabilities.
Redundant Power System
UniFi SmartPower RPS, USP-RPS, is our PSU failover system.
Power Supply Failure
In the event of a UniFi switch power supply failure, the USP-RPS automatically supplies redundant power to the failed device.
UniFi SmartPower
One UniFi SmartPower device can support up to 6 devices until the failed device is replaced.
Touchscreen Display
The 1.3″ touchscreen display allows easy monitoring and quick troubleshooting.
Synchronized LCM Displays
Touch one to wake up all the screens and view a rich set of information.
System Information
Errors
Warnings
Port Statistics
PoE Power
Throughput
And a lot more..
Specifications
Power Budget
95W PoE
RJ45 Ports
(24) 10/100/1000 RJ45 Ports
PoE+ Ports
(1-16) IEEE 802.3af/at
PoE++
No
SFP
(2) 1G SFP Ethernet Ports
SFP+
No
LCM
Yes
USP-RPS Power Redundancy
No
Dimensions
442.4 x 200 x 43.7 mm
| Weight | 4.05 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.
CERTIFICATION
| Certification | CE, FCC, IC |
DATA TRANSMISSION
| Switching capacity | 52 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 38.69 Mpps |
| Throughput | 26000 Mpps |
| Static route | Yes |
DESIGN
| Certification | CE, FCC, IC |
| Rack mounting | Yes |
| Form factor | 1U |
| LED indicators | Activity, Link, PoE, Speed, System |
| Product colour | Silver |
ENERGY MANAGEMENT
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| DC input voltage | 44 - 57 V |
| Power supply included | Yes |
LOGISTICS DATA
| Harmonized System (HS) code | 85176990 |
MANAGEMENT FEATURES
| Switch layer | L2/L3 |
| Switch type | Managed |
NETWORKING
| Full duplex | Yes |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Flow control support | Yes |
| Port mirroring | Yes |
| Auto MDI/MDI-X | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -5 - 40 °C |
PERFORMANCE
| Harmonized System (HS) code | 85176990 |
PORTS & INTERFACES
| Installed SFP+ modules quantity | 0 |
| Installed SFP modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP module slots quantity | 2 |
POWER OVER ETHERNET (POE)
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Total Power over Ethernet (PoE) budget | 92 W |
| Power over Ethernet (PoE) power per port | 32 W |
SECURITY
| Authentication type | IEEE 802.1x, RADIUS |
WEIGHT & DIMENSIONS
| Weight | 3 kg |
| Height | 43.7 mm |
| Width | 442.4 mm |
| Depth | 200 mm |
