Ubiquiti UAP-AC-LR-5 UniFi Long Range Wireless AC1300 Dual Band PoE Access Point (5 Pack)
| Type | Long Range |
| Speed | AC1300 |
| Indoor or Outdoor | Indoor |
| POE Capability | 48v |
| Pack Size | 5 Pack |
£ 293.62
Guaranteed Safe Checkout
Please note, the Ubiquiti multipack models such as this one do not include the POE Injector. If you need this item please be aware you need to order it separately alongside the multipacks. codes are NPUBI-POE4824W and NPUBI-POE4824WG
802.11ac Long Range Access Point (5 PACK)
The UniFi AC LR AP features the latest Wi-Fi 802.11ac technology in a refined industrial design and is ideal for long-range deployment of high-performance wireless networks.
Innovative Antenna Design
The innovative antenna design provides a long-range, symmetrical-link coverage area, and the antenna gain of the UniFi AC LR AP performs better than one-way, high transmit power does for connecting distant clients.
Designed for Optimal RF Performance
The newly redesigned UniFi Controller optimizes RF performance:
Scalable Enterprise Wi-Fi Management
The UniFi Controller v5 software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralized controller. Remotely access the UniFi Controller to upgrade deployed UniFi APs while in the field.
Specifications
Model: UAP-AC-LR
Dimensions: 175.7×43.2mm
Environment: Indoor
2.4GHz Speed: 450Mbps
5GHz Speed: 867Mbps
PoE Mode: 802.3af/A PoE & 24V PoE
Ports: (1) 10/100/1000 Ethernet
| Weight | 0.24 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.
ANTENNA
| Antenna gain level (max) | 3 dBi |
| Antennas quantity | 1 |
CERTIFICATION
| Certification | CE, FCC, IC |
DESIGN
| Internal | No |
| Certification | CE, FCC, IC |
| Product colour | White |
| Reset button | Yes |
ENERGY MANAGEMENT
| Input current | 0.5 A |
| AC input voltage | 24 V |
| Power consumption (max) | 6.5 W |
FEATURES
| Maximum data transfer rate | 1000 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum indoor range | 183 m |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
LOGISTICS DATA
| Harmonized System (HS) code | 85176990 |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -10 - 70 °C |
PACKAGING CONTENT
| Mounting kit | Yes |
PACKAGING DATA
| Mounting kit | Yes |
PORTS & INTERFACES
| Ethernet LAN (RJ-45) ports | 1 |
SECURITY
| Security algorithms | AES, TKIP, WEP, WPA, WPA-PSK, WPA2 |
TECHNICAL DETAILS
| Harmonized System (HS) code | 85176990 |
WEIGHT & DIMENSIONS
| Weight | 240 g |
| Height | 43.2 mm |
| Width | 175.7 mm |
| Depth | 175.7 mm |
