Ubiquiti NBE-5AC-GEN2 NanoBeam 5AC Gen 2 High Performance airMAX Outdoor Wireless AC CPE Bridge
| Type | CPE |
| Speed | 450+ Mbps |
| POE Capability | 24v |
| Range | 15+ km |
| Antenna Gain | 19 dBi |
£ 63.25
Guaranteed Safe Checkout
Incorporating innovative industrial design with proprietary airMAX ac technology, the NanoBeam AC is ideal for CPE deployments requiring maximum performance from the smallest possible footprint.
Management Wi-Fi Radio
The NanoBeam AC integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.
Improved Surge Protection
The NanoBeam AC features enhanced protection against ESD events.
Superior Processing
Ubiquiti’s airMAX engine with custom IC dramatically improves TDMA latency and network scalability. The custom silicon provides hardware acceleration capabilities to the airMAX scheduler, to support the high data rates and dense modulation used in airMAX ac technology.
Incredible Antenna ?Beam? Performance
The form factor of the NanoBeam® AC features the highest gain for its size. The NanoBeam AC’s excellent beam directivity provides the best performance in high-noise environments.
Performance Breakthrough
airMAX ac products offer improved latency, noise immunity, scalability and significantly increased throughput performance.
Advanced Software Technology
Ubiquiti’s airMAX technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.
Plug and Play Installation
The NanoBeam AC mounts to a variety of surfaces including poles or walls, and offers the freedom of three-axis alignment. No screws are required for pole-mounting, and only a single wall screw (not included) is required for wall-mounting.
Now with airOS®8
airOS®8 provides powerful features, including airMAX ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
| Weight | 1.15 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.
ANTENNA
| Antenna gain level (max) | 19 dBi |
CERTIFICATES
| Certification | CE, FCC, IC, RoHS |
| Compliance certificates | CE, RoHS |
DATA TRANSMISSION
| Maximum data transfer rate | 450 Mbit/s |
| Maximum transfer distance | 15000 m |
ENERGY MANAGEMENT
| Power over Ethernet (PoE) | Yes |
| DC output current | 0.5 A |
| Power source type | PoE |
| Power consumption (max) | 8.5 W |
| DC output voltage | 24 V |
FEATURES
| Processor frequency | 720 MHz |
| Internal memory | 128 MB |
| Processor model | MIPS 74Kc |
| Material | Plastic |
| LED indicators | LAN, Power, Signal strength |
| Product colour | White |
| Processor family | Atheros |
| Reset button | Yes |
| Mounting type | Wall/Pole |
| Surge protection | Yes |
| RAM type | DDR2 |
| Product type | Network bridge |
LOGISTICS DATA
| Harmonized System (HS) code | 85176990 |
MANAGEMENT FEATURES
| Web-based management | Yes |
MEMORY
| Flash memory | 8 MB |
| RAM capacity | 128 MB |
| RAM type | DDR2 |
NETWORKING
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 80 °C |
| Operating temperature (T-T) | -40 - 176 °F |
PACKAGING CONTENT
| Cables included | AC |
| Mounting bracket(s) included | Yes |
| PoE+ Injector(s) | Yes |
PACKAGING DATA
| Quantity per pack | 1 pc(s) |
PORTS & INTERFACES
| Ethernet LAN (RJ-45) ports | 2 |
PROCESSOR
| Processor frequency | 720 MHz |
| Processor model | MIPS 74Kc |
| Processor family | Atheros |
SECURITY
| Security algorithms | WPA2 |
TECHNICAL DETAILS
| Harmonized System (HS) code | 85176990 |
| Sustainability certificates | CE, RoHS |
| Compliance certificates | CE, RoHS |
WEIGHT & DIMENSIONS
| Weight | 530 g |
| Height | 125 mm |
| Width | 189 mm |
| Depth | 189 mm |
WIRELESS LAN FEATURES
| Modulation | 16-QAM, 64-QAM, 256-QAM, BPSK, QPSK |
| Frequency band | 5.15 - 5.875 |
| Wi-Fi | 5.15 - 5.25 |
| 5.25 - 5.35 | |
| 5.47 - 5.725 | |
| 5.725 - 5.85 GHz | |
| Yes |
