Ubiquiti ACB-ISP airCube ISP airMAX Home Wi-Fi Access Point with Integrated 24V PoE Passthrough
| Type | Router |
| Speed | N/A |
| POE Capability | 24v |
| Range | N/A |
| Antenna Gain | N/A |
£ 19.40
Guaranteed Safe Checkout
airMAX Home Wi-Fi Access Point
With a compact design and integrated 24V PoE passthrough, the airCube is a home Wi-Fi access point designed to interoperate with airMAX CPEs.
UNMS Support
Ubiquiti Network Management Software simplifies remote network management.
Super Antenna
Innovative Super Antenna provides wide-area coverage beyond regular Wi-Fi access points.
24V PoE Passthrough
The airCube can be powered by and provide power to an airMAX CPE using 24V PoE.
UNMS Mobile Support
Use the intuitive UNMS Mobile app for iOS and Android to install and configure airCube.
Sleek Design
The airCube’s attractive design means it can be positioned anywhere in the room, improving Wi-Fi performance.
Specifications
24V PoE Passthrough
Yes
Power Supply
24V PoE or 5V Micro USB (Not included)
Wi-Fi Standards
802.11n 2×2
Ethernet Ports
4x 10/100 Mbps
Frequency
2.4GHz
UMobile and UNMS Support
Yes
| Weight | 0.349 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.
ANTENNA
| Antenna gain level (max) | 4 dBi |
CERTIFICATION
| Certification | CE,. FCC, IC |
DESIGN
| Internal | No |
| Certification | CE,. FCC, IC |
| LED indicators | Status |
| Product colour | Black |
| Housing material | Plastic |
| Placement | Floor, Table |
ENERGY MANAGEMENT
| Power over Ethernet (PoE) | Yes |
| Power consumption (max) | 5 W |
FEATURES
| Maximum data transfer rate | 300 Mbit/s |
| Networking standards | IEEE 802.11n |
| Ethernet LAN data rates | 10,100 Mbit/s |
| 2.4 GHz | Yes |
| 5 GHz | No |
LOGISTICS DATA
| Harmonized System (HS) code | 85176990 |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -10 - 50 °C |
PORTS & INTERFACES
| USB connector type | Micro-USB |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
TECHNICAL DETAILS
| Harmonized System (HS) code | 85176990 |
WEIGHT & DIMENSIONS
| Weight | 280 g |
| Height | 87.8 mm |
| Width | 89.5 mm |
| Depth | 89.2 mm |
