TP-Link TL-SG105 5-Port 10/100/1000Mbps Metal Gigabit Desktop Switch

Ports	5 Ports
Managed/Unmanaged	Unmanaged
Speed	10/100/1000
PoE capable	No

£ 13.11

Add to wishlist

Guaranteed Safe Checkout

Conveniently Conduct Business
The TL-SG105 Desktop Switch provides an easy way to increase the speed of your network server and backbone connections. Whether you are at home or in the office, the TL-SG105 helps you deal with your business quickly and easily, any time.

Plug and Play, No Configuration Required
A plug-and-play design makes for easy deployment, no technician needed. Auto-negotiation on each port senses the link speed of a network device and intelligently adjusts to ensure full compatibility and optimal performance.

Five Gigabit Ports for Faster Speeds
Increase the speed of your network with the TL-SG105 5-port Gigabit desktop switch. 5 non-blocking 10/100/1000 Mbps ports enable instant transferring of large, bandwidth intensive files without interference.

Key Features
5x 10/100/1000 Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
Plug and play, no configuration needed
Supports 802.1p/DSCP QoS and IGMP Snooping functions
Durable metal casing, desktop/wall-mounting options, and a fanless design
IEEE 802.3x flow control provides reliable data transfer
Green Ethernet technology reduces power consumption

Specifications

HARDWARE FEATURES

Standards and Protocols
IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p

Interface
5x 10/100/1000 Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports

Fan Quantity
Fanless

External Power Supply
External Power Adapter (Output: 5 V DC / 0.6A)

LED Indicator
System Power
Link/Act indicators per port built into each RJ-45 port

Dimensions ( W x D x H )
3.9 x 3.9 x 1.0 in (100 x 98 x 25 mm)

Max Power Consumption
2.3 W (220 V/ 50 Hz)

Max Heat Dissipation
7.83 BTU/h

PERFORMANCE

Packet Forwarding Rate
7.4 Mpps

MAC Address Table
2K

Packet Buffer Memory
1 Mb

Jumbo Frame
16 KB

SOFTWARE FEATURES

Advanced Features
Green Technology
802.3X Flow Control
802.1P/DSCP QoS (for V2 and later version)
IGMP Snooping

Transfer Method
Store and Forward

OTHERS

Certification
CE, FCC, RoHS

Package Contents
5-Port 10/100/1000Mbps Desktop Switch
Power Adapter
Installation Guide

Environment
Operating Temperature: 0 – 40
Storage Temperature: -40 – 70
Operating Humidity: 10 – 90% RH non-condensing
Storage Humidity: 5 – 90% RH non-condensing

Weight	0.35 lbs
Manufacturer	TP-LINK
EAN	6935364021146
Manufacturer Code	TL-SG105

Manufacturer’s Website:
www.tp-link.com
Warranty:
3 Years Return to Base Warranty.

CERTIFICATES

Certification	CE, FCC, RoHS

DESIGN

LED indicators	Y
Colour of product	Black

ENERGY MANAGEMENT

Input current	0.6 A
Power consumption (max)	2.3 W
Input current	0.6 A
AC input frequency	50 Hz
Power consumption (max)	2.3 W

FEATURES

Certification	CE, FCC, RoHS
LED indicators	Yes
Product colour	Black
LED indicators	Y
Housing material	Steel
Product colour	Black
Housing material	Steel

LOGISTICS DATA

Harmonized System (HS) code	85176990

NETWORKING

Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x

OPERATIONAL CONDITIONS

Operating relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
Operating relative humidity range	10 - 90%
Storage temperature (T-T)	-40 - 70 °C
Operating temperature range (T-T)	0 - 40 °C
