Mercusys MB230-4G 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router
| Type | Router |
| Speed | 1200 Mbps |
| PoE | No |
£ 45.01
Guaranteed Safe Checkout
4G+ network – Enjoy the 4G+ Cat 6 download speeds up to 300 Mbps.
Plug a SIM card and play – No configurations needed, compatibility of SIM cards are assured by years of field tests.
Dual Band 1200 Mbps WiFi – Fast WiFi speeds up to 300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band.
Simultaneous Connection – Enjoy and share internet access with up to 64 Wi-Fi devices.
Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can’t get a 4G connection.
Specifications
Wireless
Wireless Standards
IEEE 802.11ac/a/b/g/n
Frequency
5 GHz, 2.4 GHz
Signal Rate
867 Mbps at 5 GHz
300 Mbps at 2.4 GHz
Reception Sensitivity
11g 6Mbps: -95dBm
11g 54Mbps: -77dBm
11n HT20 MCS7: -74dBm
11n HT40 MCS7: -71dBm
11a 6Mbps: -92dBm
11a 54Mbps: -75dBm
11ac VHT20 MCS8: -70dBm
11ac VHT40 MCS9: -65dBm
11ac VHT80 MCS9: -61dBm
Transmission Power
2.4 GHz < 20dBm (EIRP)
5 GHz < 23dBm (EIRP)
Wireless Security
WPA-PSK / WPA2-PSK / WPA3-SAE
Wireless Functions
Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics
Software
DHCP
Server
Hardware
Dimensions (W x D x H)
95x61.05x165.97 mm
Interfaces
1x Gigabit LAN/WAN Port
1x Gigabit LAN Port
1x Nano SIM Card Slot
Button
WPS/Reset Button
Network Type
EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
Others
Package Contents
4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router (MB230-4G)
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
| Weight | 0.0 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Manufacturer’s Website:
www.mercusys.com
Warranty:
3 Years Return to Base Warranty.
ANTENNA
| Antenna design | Internal |
DESIGN
| Product colour | White |
| Indication light | Yes |
| Product type | Desktop/pole router |
FEATURES
| Firmware upgradeable | Yes |
MANAGEMENT FEATURES
| Reset button | Yes |
| WPS push button | Yes |
| Wi-Fi Multimedia�(WMM)/(WME) | Yes |
MOBILE NETWORKING
| Dual SIM support | No |
| 3G bands supported | 850,900,2100 MHz |
| SIM card type | NanoSIM |
| 4G bands supported | 700,800,850,900,1800,2100,2300,2600 MHz |
| 4G standard | LTE-TDD & LTE-FDD |
| 3G standards | HSPA, HSPA+, UMTS |
| SIM card slot | Yes |
| Mobile network generation | 4G |
NETWORKING
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Receiver sensitivity | 11g 6Mbps: -95dBm |
| Networking standards | 11g 54Mbps: -77dBm |
| Ethernet LAN data rates | 11n HT20 MCS7: -74dBm |
| Port forwarding | 11n HT40 MCS7: -71dBm |
| Dynamic DNS (DDNS) | 11a 6Mbps: -92dBm |
| Ethernet LAN interface type | 11a 54Mbps: -75dBm |
| Port triggering | 11ac VHT20 MCS8: -70dBm |
| 11ac VHT40 MCS9: -65dBm | |
| 11ac VHT80 MCS9: -61dBm | |
| IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | |
| 10,100,1000 Mbit/s | |
| Yes | |
| Yes | |
| Gigabit Ethernet | |
| Yes |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
PACKAGING CONTENT
| AC adapter included | Yes |
| Quick installation guide | Yes |
PACKAGING DATA
| AC adapter included | Yes |
| Package type | Box |
| Quick installation guide | Yes |
| Number of products included | 1 pc(s) |
PORTS & INTERFACES
| Ethernet LAN (RJ-45) ports | 2 |
| DC-in jack | Yes |
| USB port | No |
POWER
| Output voltage | 12 V |
| Output current | 1 A |
| Power source type | DC |
PROTOCOLS
| VoIP protocols | IPv4, IPv6 |
| DHCP server | Yes |
| Universal Plug and Play (UPnP) | Yes |
SECURITY
| Security algorithms | 64-bit WEP, WPA-PSK, WPA2-PSK, WPA3-SAE |
| System event log | Yes |
| DMZ support | Yes |
| Firewall | Yes |
| Port-based Network Access Control (PNAC) | Yes |
WAN CONNECTION
| Dual SIM support | No |
| WAN connection type | RJ-45 |
| DSL WAN | No |
| Ethernet WAN | Yes |
| SIM card slot | Yes |
| 3G/4G USB modem compatibility | Yes |
WEIGHT & DIMENSIONS
| Height | 166 mm |
| Width | 95 mm |
| Depth | 61 mm |
WIRELESS LAN FEATURES
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 1200 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
