Mercusys MA30E AC1200 WiFi Bluetooth PCIe Adapter
| Type | Adapter |
| Speed | 1200 Mbps |
| PoE | No |
£ 12.40
Guaranteed Safe Checkout
Strong Dual Band Wi-Fi Speed — Speeds up to 867 Mbps (5 GHz) + 300 Mbps (2.4 GHz)
Wider Signal Coverage — Two high-performance antennas
Bluetooth 5.0 — The Bluetooth 5.0 technology achieves faster speeds and broader coverage
MU-MIMO — Simultaneously serve several devices with no more latency or bandwidth congestion
Improved Security — The latest security enhancement, WPA3, provides enhanced protection in personal password safety
Backward Compatibility — Full support for 802.11ac/a/b/g/n standards
Windows Compatible — Supported operating system: Windows 10, 11 (64 bit)
Specifications
Wireless
Wireless Standards
IEEE 802.11 a/n/ac 5 GHz
IEEE 802.11 b/g/n 2.4 GHz
Signal Rate
867 Mbps on 5 GHz
300 Mbps on 2.4 GHz
Reception Sensitivity
5 GHz:
11a 54Mbps: -77 dBm
11ac VHT80 MCS0: -92dBm
11ac VHT80 MCS9: -64dBm
2.4 GHz:
11g 54Mbps: -76 dBm
11n HT40 MCS7: -72dBm
Wireless Security
WPA-PSK/WPA2-PSK/WPA3-SAE
Hardware
Dimensions (W x D x H)
8.9 x 4.8 x 0.85 in (226.3 x 120.8x 21.5 mm)
Antenna Type
2x Fixed High-Performance Omni-Directional Antennas
Others
Package Contents
AC1200 Wi-Fi Bluetooth 5.0 PCIe Adapter (MA30E)
Bluetooth Header Cable
Quick Installation Guide
Resource CD
| Weight | 0.15 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Manufacturer’s Website:
www.mercusys.com
Warranty:
3 Years Return to Base Warranty.
DESIGN
| Internal | Yes |
| Certification | FCC, CE, RoHS |
| Receiver sensitivity | 5 GHz: 11ac HT80: -59.0dBm |
| Product colour | 11n HT40: -68.5dBm |
| Antenna | 11a 54Mbps: -73.5dBm |
| Component for | 11a 6Mbps: -91dBm , 2.4 GHz: 11n HT40: -69.5dBm |
| Antenna direction type | 11g 54Mbps: -74dBm |
| 11b 11Mbps: -87dBm | |
| Black | |
| Yes | |
| PC | |
| Omni-directional |
NETWORKING
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Security algorithms | WPA-PSK, WPA2-PSK, WPA3-SAE |
| Maximum data transfer rate | 1200 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi | Yes |
| WLAN data transfer rates supported | 11,54,300,867 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
OPERATIONAL CONDITIONS
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
PACKAGING CONTENT
| Quick installation guide | Yes |
| Resource CD | Yes |
PORTS & INTERFACES
| Interface | WLAN / Bluetooth |
| Connectivity technology | Wireless |
| Host interface | PCI Express |
SYSTEM REQUIREMENTS
| Windows operating systems supported | Windows 10, Windows 11 |
WEIGHT & DIMENSIONS
| Height | 21.5 mm |
| Width | 226.3 mm |
| Depth | 120.8 mm |
