DeepCool CH690 Digital ATX Mid-Tower Case, High-Airflow PC Case with Semi-Glass Panel, USB-C Port, Support for 420mm Radiator, 450mm GPU, ATX PSU, White
| Form Factor | Mid Tower |
| Motherboard Support | ATX |
| PSU Included | None |
| Case Colour | White |
| LED Colour | None |
| USB 3.0 | 2 |
| Side Panel | Tempered Glass |
£ 61.80
Guaranteed Safe Checkout
The DeepCool CH690 Digital White ATX Case is designed with beauty and adaptability in mind. It features a semi-glass panel that offers an expansive view of installed components. For those seeking enhanced performance, the rear of the case supports DIY modifications, allowing users to replace the semi-glass panel with a mesh panel and fan bracket to boost horizontal airflow. Additionally, the integrated light strip slot enables the addition of light strips to create an immersive gaming atmosphere, blending aesthetics with functionality for a truly personalized setup.
Specifications
Model Number:
R-CH690-WHNNA0D-G-1
Case Type:
Mid-Tower
Motherboard Support:
Mini-ITX, Micro-ATX, ATX
Dimensions:
552mm (L) x 332mm (W) x 589mm (H)
Net Weight:
9.8 kg
Materials:
ABS, SPCC, Tempered Glass
Front I/O Ports:
2 x USB 3.0
1 x USB Type-C (Gen 2)
1 x HD Audio/Mic
Drive Bays:
1 x 3.5″ Drive Bay
2 x 2.5″ Drive Bays
Expansion Slots:
8
Pre-Installed Fans:
None
Fan Support:
Top: 3 x 120mm / 3 x 140mm
Side: 3 x 120mm / 3 x 140mm
PSU Shroud: 3 x 120mm / 3 x 140mm
Rear: 1 x 120mm / 1 x 140mm
Radiator Support:
Top: 120mm / 140mm / 240mm / 280mm / 360mm / 420mm
Side: 120mm / 140mm / 240mm / 280mm
PSU Shroud: 120mm / 240mm / 360mm
CPU Cooler Height Limit:
182mm
GPU Length Limit:
450mm
Power Supply Type:
ATX PS2 (maximum length: 180mm)
Warranty:
1 Year
| Weight | 9.8 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Manufacturer’s Website:
uk.deepcool.com
Warranty:
1 Year Return To Base Warranty
COOLING
| Top fans diameters supported | 120,140 mm |
| Bottom fans diameters supported | 140 mm |
| Number of side fans supported (max) | 3 |
| Number of rear fans supported (max) | 1 |
| Number of top fans supported (max) | 3 |
| Number of bottom fans supported (max) | 3 |
| Liquid cooling capability | Yes |
| Top radiator fan sizes supported | 120,140,240,280,360,420 mm |
| Bottom radiator fan sizes supported | 120,240,360 mm |
| Side radiator fan sizes supported | 120,140,240,280 mm |
DESIGN
| Type | PC |
| Form factor | Tower |
| Material | Acrylonitrile butadiene styrene (ABS), SPCC, Tempered glass |
| Product colour | White |
| Cable management | Yes |
| Reset button | Yes |
| Supported motherboard form factors | ATX, micro ATX, Mini-ITX |
| Number of 5.25" bays | 0 |
| Number of 3.5" bays | 1 |
| Suitable for | Gaming |
| Side window | Yes |
| Maximum CPU cooler height | 18.2 cm |
| Maximum graphics card length | 45 cm |
| Number of expansion slots | 8 |
| Maximum PSU length | 18 cm |
| Number of 2.5" bays | 3 |
| On/off button | Yes |
| Tempered glass panel(s) | Yes |
DISPLAY
| Built-in display | Yes |
| Display type | LCD |
PORTS & INTERFACES
| USB 2.0 ports quantity | 0 |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 0 |
POWER SUPPLY
| Power supply location | Bottom |
| Power supply included | No |
| Supported power supply form factors | ATX, PS2 |
STORAGE
| Supported HDD sizes | 2.5,3.5" |
| SSD form factor | 2.5" |
WEIGHT & DIMENSIONS
| Weight | 9.8 kg |
| Height | 516 mm |
| Width | 240 mm |
| Depth | 481 mm |
