ANTEC AX20 Case, Black, Mid Tower, 1 x USB 3.0 / 2 x USB 2.0, Tempered Glass Side Window Panel, Slanted Bar & Mesh Design for Massive Airflow, 3 x RGB LED Fans Included, ATX, Micro ATX, Mini-ITX
| Form Factor | Mid Tower |
| Motherboard Support | ATX |
| PSU Included | None |
| Case Colour | Black |
| LED Colour | RGB |
| USB 3.0 | 1 |
| Side Panel | Tempered Glass |
£ 29.74
Guaranteed Safe Checkout
AX20
Mid-Tower Gaming Case
Unique Design & Powerful Heat Dissipation
AX20 features a slanted bar air intake design and an exceptional dense mesh for massive heat dissipation. The half-view tempered glass side panel design allows you to show off your gaming configurations without obstacles. The AX20 supports up to 8 x 120 mm fans simultaneously and provides users with diverse cooling options.
Slanted Bar Air Intake Design
Featuring dense mesh for massive airflow and efficient dust prevention.
High-Airflow Front Panel
Massive air intake at the front, top, and bottom. Creating multiple airflow paths.
Pre-Installed
3 x 120mm RGB Fixed Model Fans
Form Factor
Mid Tower
Materials
Steel
Plastic
Mainboard Support
ATX
Micro ATX
Mini-ITX
RGB
FRGB so no header
I/O Panel
Power
Reset
2 x USB 2.0
1 x USB 3.0
MIC / HD-AUDIO
Side Panel
Tempered glass
Drive Bays
3.5″ / 2.5″: 2 / 1
2.5″: 2
Expansion
Slots: 7
Fan Support
Front: 3 x 120mm / 2 x 140mm
Top: 2 x 120mm
Power Supply Shroud: 2 x 120mm
Rear: 1 x 120mm
Included Fans
3 x 120 RGB fixed model fans in front
Radiator Support
Front: 120 / 140 / 240 / 280mm
Clearance
Max GPU Length: = 270mm
Max CPU Cooler Height: = 155mm
Max PSU Length: = 170mm (with HDD) / = 295mm (without HDD)
Dust Filter
Front
Weight
Net: 4 Kgs
Gross: 4.71 Kgs
Dimensions ( D x W x H )
358 x 207 x 451mm
| Weight | 4.7 lbs |
|---|---|
| Manufacturer | |
| EAN | |
| Manufacturer Code |
Manufacturer’s Website:
www.antec.com
Warranty:
1 Year Return To Base Warranty
COOLING
| Number of rear fans supported (max) | 1 |
| Number of top fans supported (max) | 2 |
| Front radiator fan sizes supported | 120,140,240,280 mm |
DESIGN
| Type | PC |
| Form factor | Midi Tower |
| Material | Plastic, Steel, Tempered glass |
| Product colour | Black |
| Reset button | Yes |
| Supported motherboard form factors | ATX, ITX, micro ATX |
| Anti-dust filter | Yes |
| Number of 3.5" bays | 2 |
| Side window | Yes |
| Maximum CPU cooler height | 15.5 cm |
| Maximum graphics card length | 27 cm |
| Number of expansion slots | 7 |
| Maximum PSU length | 17 cm |
| Number of 2.5" bays | 3 |
| On/off button | Yes |
PACKAGING DATA
| Package weight | 4.71 kg |
PORTS & INTERFACES
| Audio input | Yes |
| Audio output | Yes |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
POWER SUPPLY
| Power supply included | No |
WEIGHT & DIMENSIONS
| Weight | 4 kg |
| Height | 451 mm |
| Width | 207 mm |
| Depth | 358 mm |
